ESAB® Dual Shield® II 712X .045" Flux-Cored Welding Wire, 33# Wire Spool

Details:

Dual Shield II 712X is an all-position flux cored wire intended for applications requiring outstanding weld metal toughness. This X Series wire, in combination with 75% Argon/25% CO2 shielding gas, can produce Charpy V-Notch impact results of more than 40 ft-lb (68 J) at -60°F (-51°C) and Crack Tip Opening Displacement (CTOD) results of more than 20 mils (0.5 mm) at -40°F (-40°C). Dual Shield II 712X also provides the smooth arc and low spatter levels characteristic of Dual Shield flux cored wires. Applications include off-shore oil components, shipbuilding and heavy equipment where exceptional Charpy impact/low temperature toughness is required.

Specifications:

• Country of Origin: United States
• Trade Name: DUAL SHIELD®
• Carcinogen: Lead
• Reproductive: Dual Short Form
• Material: Mild Steel
• Process: FCAW
• Diameter: 0.045"
• Tensile Strength: 83ksi
• AWS Classification: E71T-1MJH8/T-9MJH8/T-12MJH8
