Bobcat™ 230 (Kohler) Gas Welder
Based on unit price: $8,867.59
- Description
- Spec. Sheets
- Rebate
Details:
Reliable multiprocess engine-driven welder primarily used for Stick welding and creating power. Cost-effective engine-driven welder designed for maintenance and repair operations, construction, field fabrication, farm/ranch and work trucks.
Features:
- Full auxiliary power at any setting.
- Easy arc starts and less spatter.
- Over 100 pounds lighter and 13 percent smaller than previous models.
- Single knob adjustment for quick and precise setup.
- Kohler or Vanguard.
- With its intuitive design, the daily maintenance of our engine-driven welder is fast and easy.
Specifications:
- Country of Origin: United States
- Length: 37.06
- Width: 20.13
- Height: 26.5
- Weight: 376
- Engine Weld Speed: 3600
- Rated Output: CC/DC Stick 230 A at 29.2 V, 100% duty cycle, CV/DC MIG/FCAW 230 A at 25.5 V, 100% duty cycle
- Fuel Type: Gasoline
- Sound Rating: 64 dB @ idle and 73 dB @ weld
- Engine Brand: Kohler
- Horsepower (hp): 23.5
- Single-Phase Generator Peak Power (W): 11000
- Weld Output: CC / CV
- Fuel Tank Size: 11 Gallon
- Single-Phase Generator Continuous Power (W): 9500
- Engine Idle Speed: 2300 RPM
- Min DC Welding Amperage: 20
- Max DC Welding Amperage: 230
- Amperage Range: 20 A - 230 A
- Current Type: DC
- Weldable Metals: Stainless Steel|Steel
How to Claim Your Rebate – Step-by-Step:
1. Purchase a qualifying Miller product.
Choose eligible welders, safety gear, or welding tables listed on the promotion flyer (or by clicking here) between April 1 and June 30, 2025.
2. Collect your proof of purchase.
-
Save an electronic copy of your invoice or receipt.
-
Circle each eligible product and accessory.
-
Note the serial number of each qualifying item.
3. Submit your rebate claim.
Visit MillerRebateCenter.com or scan the QR code on your flyer.
You must submit your claim within 30 days of purchase.
4. Get paid.
Once approved, receive your rebate (typically a prepaid card or cheque) within 6–8 weeks.
